ePMP Bridge in a Box – 5 GHz (FCC)
Cambium ePMP Bridge in a Box: Plug-n-Play Outdoor Wireless Ethernet Bridge
Plug-n-play Outdoor Wireless Solution
The two ePMP Force 180 units are pre-paired and pre-configured, so set-up is quick and simple. Installation can be completed using the included flexible pole mount, adjustable wall bracket or a combination of both. With a wireless range of up to 10 miles, this bridge-in-a-box can be used for:
- Extend a local network to a remote building
- Extend your Wi-Fi link to a new location
- Provide a cost-effective solution to backhauling CCTV networks
- Support any application requiring network extension!
Quick look at the ePMP Bridge-in-a-Box Features:
- FREQUENCY: 4910-5970 MHz
- THROUGHPUT: up to 200 MBps
- FLEXIBLE CHANNEL WIDTH: 5, 10, 20, 40 MHz channels
- SECURITY: AES128 data encryption and RADIUS-based authentication
- RANGE: Up to 10 miles.
Extend a Local Network to a Remote Building
Easily support any application requiring network extension with these pre-paired Force 180 5-GHz units. These superior models deliver 1W (30dBm) of power anywhere within a 10-mile range and are each equipped with a gigabit ethernet port for maximum throughput. ePTP proprietary protocol supports longer ranges and strong interference tolerance, delivering reliable and consistent performance. The adjustable mounting bracket allows you to position the units for optimum performance, and the discreet low profile design will not draw attention or take away from your building's aesthetic.
Secure, Reliable, and Cost-effective Solution for Wireless Backhaul
These, outdoor-rated wireless units will ensure privacy and protect data access and usage.
- Built-in 128 bit AES military-grade data encryption and RADIUS-based authentication
- Integrated high-gain 16 dBi patch antenna
- Discreet low-profile design
- Outdoor-rated, waterproof, dustproof, industrial-grade casing
Specifications C058900B072A
Spectrum | |
Channel Spacing | Configurable on 5MHz increments |
Frequency Range | 5GHz: 4910 - 5970MHz (exact frequencies as allowed by local regulations) |
Channel Width | 5/10/20/40MHz |
MAC (Media Access Control) Layer | Cambium Proprietary |
Physical Layer | 2x2 MIMO/OFDM |
Ethernet Interface | 10/1001000BaseT, Compatible with Cambium PoE pinouts and standard PoE pinouts |
Protocols Used | IPv4, UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping |
Network Management | Https, SNMPv2c, SSH |
VLAN | 802.1Q with 802.1p priority |
Performance | |
ARQ | Yes |
Nominal Receive Sensitivity (w/FEC) @ 200MHz Channel | MCS0 = -93dBm to MCS15 = -72dBm (per branch) |
Nominal Receive Sensitivity (w/FEC) @ 40MHz Channel | MCS0 = -90dBm to MCS15 = -69dBm (per branch) |
Modulation Levels (adaptive) | MCS0 (BPSK) to MCS15 (64QAM 5/6) |
Quality of Service | Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP and MAC Address, Broadcast, Multicast, and Station Priority |
Physical | |
Transmit Power Range | -17 to +30dBm (combined, to regional EIRP limit) (1dB interval) |
Integrated Antenna Peak Gain | 16dBi |
Maximum Transmit Power | 30dBm combined (subject to regional regulatory restrictions) |
Antenna Connection | Integrated Antenna |
Surge Suppression | 2 Joule Integrated |
Environmental | IP55 |
Temperature | -30 to 60°C (-22 to 140°F) |
Weight | 0.50kg (1.1lbs) (includes mounting bracket) |
Wind Survival | 145km/h (90mi/h) with antenna |
Dimensions | 12.4 x 25.1 x 11.9cm (4.9 x 9.9 x 4.7") - with mounting bracket attached |
Pole Diameter Range | 1 to 1.6" (2.5 to 4.1cm) with included clamp; up to 2.25" (5.7cm) with larger clamp |
Power Consumption | 10W Maximum, 5W Typical |
Input Voltage | 10 to 30V |
Encryption | 128-bit AES (CCMP mode) |
Antenna Type | Integrated |
Typical Gain | 16dBi |
3dB Beamwidth-Azimuth | 15° |
3dB Beamwidth-Elevation | 30° |
Polarizations | Dual Linear, H/V |
Front-to-Back Isolation | >20dB |
Cross Polarization | 15dB |
