2.4 GHz PMP 450 Connectorized Subscriber Module, Uncapped

(0) No Reviews yet
SKU: C024045C008A
Manufacturer: Cambium Networks

Cambium Networks C024045C008A

2.4 GHz PMP 450 Connect SUB Uncapped

The Cambium Networks Point-to-Multipoint (PMP) 450 Access Point (AP) can provide more than 90 Mbps throughput and is interoperable with PMP 430 and PMP 100 Series Subscriber Modules (SM). Service providers with an installed base of PMP 100 subscribers can now migrate to new high-throughput PMP 450 modules to enhance overall capacity; allowing more users and/or higher rate plans.

Utilizing 2x2 MIMO-OFDM technology, new deployments can take advantage of Cambium Networks proprietary feature set, while achieving data rates higher than 90 Mbps. From the available synchronization options to its diverse feature set, the PMP 450 provides flexible deployment options that make it a good fit for high capacity, high reliability networks.

Cambium Networks provides exceptional wireless broadband connectivity solutions. With more than 3 million modules deployed in thousands of networks around the world, Cambium solutions are proven to provide cost effective, reliable data, voice and video connectivity.

Specifications C024045C008A

Frequency Range2400 - 2483.5 MHz
Radio TypeIP
Data RateUncapped
Modulation64QAM, 16QAM, QPSK, MIMO
Temperature Range-40° C to +55°C (-40° F to +131° F)
Data ConnectorsRJ-45
GPS SynchronizationYes
Latency3 - 5ms
Transmit Power22dBm
Receiver Sensitivity-73dBm to -93dBm
Antenna TypeConnectorized
Power Supply20 to 30V
Power Consumption12W
MountingIntegrated Pipe Mount
Dimensions11.75 x 3.4 x 3.4 inches
